Indoor Series
Indoor TDD eNodeB_Picocell
Model: 42132
The 42132 is an indoor 2x125mW picocell eNodeB (eNB), which offers lower cost access for indoor user equipment (UE) and solve indoor blind area problem and enhance the hotspot capacity. It is specifically used in family, small enterprise, and other indoor scenarios. As with all Prevail products, the 42132 supports Long-Term Evolution (LTE) technology, and it operates in Time Division Duplexing (TDD) mode.
With high capacity and easy deployment, the 42132 TDD series eNB can help mobile operators to provide better coverage and higher capacity with lower network deployment cost and operating expense (OPEX).
Product Details
Standard LTE TDD Bands 40/41
Customization may be requested
GUI-based local and remote Web management
Compact, all-in-one design of internal antenna
Any IP based backhaul can be used, including public transmission protected by Internet Protocol Security (IPSec)
IoT with all standard LTE Evolved Packet Core (EPC)
Peak rate (up to): DL 110 Mbps, UL 10 Mbps @ 20 MHz bandwidth
32 concurrent users
Lower power consumption to reduce OPEX
PoE+ power supply; only one Ethernet cable required for data transmission and power supply
Specification
Hardware Specifications | |
LTE Mode | TDD |
Frequency Bands | 40/41 |
Channel Bandwidth | 5/10/15/20 MHz |
Max Output Power | 21 dBm / channel |
LED Indicator | 3 x status LED PWR / LTE / ALM |
Power Supply | 12V DC, AC adaptor (multiple standards optional) PoE+ IEEE 802.3at |
Power Consumption | ≤ 15W |
Rx Sensitivity | -101 dBm |
Synchronization | GPS, 1588V2, network listening (NL) |
Interface | One RJ-45 Ethernet backhaul interface (1 GE) and one RJ-45 local Mgmt. interface (1GE) |
MIMO | DL: 2x2 |
Installation | Ceiling or wall mount, or desktop |
Antenna Type | 5 dBi built-in l omni antenna |
Dimensions (HxWxD) | 8.3 x 8.3 x 1.9 inches 210 x 210 x 48 millimeters |
Weight | 1.3 lbs / 570g |
MTBF | ≥ 150000 hours |
MTTR | ≤ 1 hour |
Software Specifications | |
LTE Standard | 3GPP Release 9 |
Peak Rate (up to)
SA - Subframe Assignment (configurable parameter)
SA1: config. 1 (DSUUD) SA2: config. 2 (DSUDD) | 20 MHz: SA1: DL 80 Mbps, UL 20 Mbps SA2: DL 110 Mbps, UL 10 Mbps 10 MHz: SA1: DL 40 Mbps, UL 7 Mbps SA2: DL 55 Mbps, UL 5 Mbps |
User Capacity | 32 concurrent users |
QoS Control | 3GPP standard QCI |
Modulation | DL: QPSK, 16QAM, 64QAM UL: QPSK, 16QAM |
Voice | VoLTE, Circuit Switched Fallback (CSFB) to GSM and UTRAN |
Traffic Offload | Local breakout |
SON | Self-organizing network: n Automatic setup n Automatic Neighbor Relation (ANR) n PCI confliction detection |
RAN Sharing | Multi-Operator Core Network (MOCN) |
Network Mgmt | TR069 |
UL Interference Detection | Supported |
Maintenance | n Remote/local maintenance n Online status management n Performance statistics n Fault management n Local or remote software upgrade n Logging n Connectivity diagnosis n Automatic start and configuration n Alarm reporting n User information tracing |
