Digital Repeater
Single Band-adjustable Digital Pico Repeater (B1)
Model: 42311D.1
Product Details
Digital bandwidth-adjustable feature allows for seamless adaptability to different frequency bands.
Multi-band options provide flexibility to meet various network requirements.
Each sub-band can be easily turned on and off, allowing for more precise control.
Separate gain control to further enhance performance.
Intelligent algorithm to prevent UL interference.
Self-control to minimize interference for new rollout e-Node B.
OMS Lite for remote/local control and monitoring.
Specification
42311D.1 | Uplink | Downlink | |
Frequency Range | 1920 - 1980MHz | 2110- 2170 MHz | |
Bandwidth | 5/ 10/ 15/ 20/ 25/ 30/ 35/ 40 MHz Programmable | ||
Max. Gain | ≧ 80 dB | ||
AGC Control Range | ≧ 20 dB | ||
Gain Control Range | 31 dB in Step of 1dB | ||
Gain Flatness | ≦ ±2.5 dB (peak-to-peak) | ||
Output Power | ≧ 18 dBm | ≧ 23 dBm | |
Out of Band Gain | Comply with 3GPP | ||
Spurious Emission | Comply with 3GPP | ||
Spectrum Emission Mask | Comply with 3GPP | ||
ACRR | Comply with 3GPP | ||
Error Vector Magnitude | ≦ 8% | ||
Frequency Stability | ≦ ±0.01 ppm | ||
Noise Figure | ≦ 7 dB @ Max. Gain | ||
VSWR | ≦ 1.8 | ||
Group Delay | ≦ 4.5 μs | ||
Environmental Condition | IP40 | ||
Power Supply | Input: AC 100~240 V, 50/ 60 Hz; Output: DC 9 V/ 5A | ||
Power Consumption | ≦ 35 W | ||
RF Connector | 4.3-10-Female | ||
Impedance | 50 Ω (nominal) | ||
Dimension (W x H x D) | 147*107*80 mm | ||
Weight | ≦ 2 kg | ||
Operating Temperature | -10 °C to 50 °C | ||
Control & | Local | Via Micro USB | |
Remote | Via Wireless Modem (optional) | ||
