5G NR TDD Repeater
5G MIMO Band-ajustable Digital Pico Repeater (N78)
Model: 52012D
Product Details
Automated Synchronization: Ensures seamless network integration.
NSA/SA Support: Compatible with both Non-Standalone and Standalone 5G networks.
Flexible Bandwidth: Digital bandwidth adjustments allow for seamless operation across various frequency bands.
Fine-grained Control: Individual sub-bands can be easily activated or deactivated for precise performance tuning.
5G Integrated Design: Facilitates easy and rapid deployment.
Accurate Synchronization: Built-in 5G base band synchronous detection module (SDM) ensures precise timing with the donor base station.
Remote/Local Management: NMS provides comprehensive remote and local control and monitoring capabilities.
Specification
P/N: 52012D.78 | N78 (3500) | N78 (3500) | |
Frequency Range | Uplink | 3400 – 3800 MHz (adjustable) | 3400 – 3800 MHz (adjustable) |
Downlink | 3400 – 3800 MHz (adjustable) | 3400 – 3800 MHz (adjustable) | |
Number of Sub-bands | 1-3 | 1-3 | |
Bandwidth per Sub-band | 5 - 100MHz (adjustable) | 5 - 100MHz (adjustable) | |
Max. Gain | Uplink | 75±2 dB | 75±2 dB |
Downlink | 75±2 dB | 75±2 dB | |
Manual Gain Control | 25 dB in step of 1 dB | ||
Automatic Gain Control | ≧ 25 dB | ||
Gain Flatness (per sub-band) | ≦ 5 dB | ||
Max. Input Power Without Damage | 0 dBm | ||
Output Power | Uplink | 20±1 dBm | 20±1 dBm |
Downlink | 20±1 dBm | 20±1 dBm | |
Out of Band Gain | 2.5≤f_offset_CW< 5.0 MHz | ≤60 dB | ≤60 dB |
5.0≤f_offset_CW<10.0 MHz | ≤45 dB | ≤45 dB | |
10.0 MHz≤f_offset_CW | ≤35 dB | ≤35 dB | |
Spurious Emission | 9KHz-1GHz | ≦ -36 dBm | |
1GHz-12.75GHz | ≦ -30 dBm | ||
ACRR | ±20/100MHz | ≦-36dBc/30KHz | ≦-36dBc/30KHz |
±40/200MHz | ≦-40dBc/30KHz | ≦-40dBc/30KHz | |
EVM | ≦ 3.5% | ≦ 3.5% | |
Frequency Stability | ≦ ±0.01 ppm | ||
Noise Figure | ≦ 6 dB @ Max. Gain | ||
VSWR | ≦ 1.8 | ||
System Delay | ≦ 4.5 µs | ||
RF Connector | N-Female | ||
Impedance | 50 Ω | ||
Power Supply | Input: AC 100-240 V, 50/ 60Hz/Output: DC 12 V/ 3 A | ||
Power Consumption | ≦ 45 W | ||
Dimensions | 205*155*49mm | ||
Weight | ≦ 3.0 kgs | ||
IP Rating | IP30 | ||
Operating Temperature | 0 °C to 55 °C | ||
NMS | Local | Via USB Type-C | |
Remote | Via Cloud-based NMS (optional) | ||
